Hello,We are using the MCU STM32H745 in our current design.We have faced the issue of working MCU properly and below are the problem,Case 1 : At power ON, some time the MCU work properly and sometime does not work properly, when it is not work proper...
This is both in RM0038 and RM0090 ADC chapter: the description of EOC status bit says, it indicates end of conversion (if EOCS=0) or end of sequence (if EOCS=1). However, in description of EOCS bit in CR2, as well as in numerous places in the narrati...
Our main hardware controllers use the STM32F303VCT6 microcontroller, which connects via SPI to a Rock PI S. Two daughter boards that use STM32F303 microcontrollers and SPI communication can be connected to the main master board. Although the system o...
Hello forum!I'm struggling to enable the burst feature described in the applicationnote from stm.I'm using cube IDE and I configured timer1 along with DMA1 to generate a specific waveform.Problem is, that after enabling the PWM via "HAL_TIM_PWM_START...
Hello, I need help with ADC and DMA settings. My application is VERY EASY but I do not understand the setup parameters. The application is that I just start CPU and the ADC raw value should independently transfer via DMA to variable. When I need the ...
Hi,I have the following function to simulate a positive phase shifting. void TIM3_Configuration_positive_quadrature(void) { TIM_TimeBaseInitTypeDef TIM_TimeBaseStructure; TIM_OCInitTypeDef TIM_OCInitStructure; int Period; Period = 1000 / 1; // T...
I had to calculate the sine wave signal in function generator voltage and the adc value I had implemented while changing frequency the voltage and adc values are constant I had stucked in this
Is it possible to use any STM32 microcontroller, particularly the STM32H5, with the STEVAL-MKI227KA evaluation kit that based on LSM6DSV16X sensor? I’ve only found information regarding the STM32F4.
Hi!I am trying to run a 16-bit ADC on a Nucleo-H743ZI2 debug board. The measured voltage is DC, 1.25 Volts, obtained from the DAC output of the controller. ADC1 input is channel 5 (pin PB1 on the CN7 board connector is close to GNDA pin and a 6.8 µF ...
Hi all! I am new on STM32 this is my first project on STM32CubeIDE. I want to generate variable duty cycle using ADC with complementary PWM. When I did the code for one channel PWM it works well and the duty cycle varies but when I did it for the co...
