This Topic is used for Wireless Charging solution 1.Mcu C drive code: GitHub - STMicroelectronics/STWirelessCharging-C-Drivers: Standard C platform-independent drivers for wireless charging ICs 2. Python drive code, check attach file "Python_FT260_S...
Hi all,I have a question about the full bridge driver L6207Q.About the VREF signal, in my design I am going to drive it with a DAC with maximum output voltage above 1V. I would avoid to insert an attenuation stage between DAC output and L6507Q VREF i...
Hi,I have looked around for a drawing or CAD file of this evaluation board, someone who knows where it can be found? All I can find is the gerber files.Kind regards Jonatan
In the manual for the L6227Q, Section 4.6 (page 16) it talks about Non-dissipative over current protection. It says the external current sense resistor can be eliminated, I assume I should replace the sensing resistors with a short, but I tried that ...
The datasheet notifies the the exact 50% Duty limitation because of using a T-flopflop that divides the oscillator frequency by two. Figure 48 (Oscillator waveforms and their relationship with gate-driving signals) suggests that each output would be ...
Evaluating STGW60V60F for a tractor-motor inverter project. Been using power modules but would like to switch to a TO-247 package. Your datasheet states "safe paralleling" for this device and "very tight parameter distribution resulting in safer para...
there is only the brief datasheet in STMicroelectronics websitewhich is not enough to add the STOD32A to any circuit.
Our product has the ST1S14PHR step-down regulator to supply 5V to the rest of the board. The input voltage range to the regulator is 8V to 24V, and the output is 5V at 1A max. We are seeing start up issues with the supply during power supply ramp tes...
