USB Mass Storage using SD Card and DMA mechanism

Question asked by Hau Lam on Apr 27, 2018

I'm trying to use STM32F779I-EVAL to develop USB Mass Storage device with SD Card and DMA mechanism.

But i got stuck the the step  PC can not detect USB mass storage device..

I alr review all the souce code the compare with the existing source code STM32F4 .

but I can not find out the problem .

This is main.c





/* Includes ------------------------------------------------------------------*/
#include "main.h"
#include "stm32f7xx_hal.h"
#include "usb_device.h"
#include "stm32f769i_eval.h"

/* USER CODE BEGIN Includes */

/* USER CODE END Includes */

/* Private variables ---------------------------------------------------------*/

SD_HandleTypeDef hsd1;
DMA_HandleTypeDef hdma_sdmmc1_rx;
DMA_HandleTypeDef hdma_sdmmc1_tx;

UART_HandleTypeDef huart1;

NOR_HandleTypeDef hnor1;
SRAM_HandleTypeDef hsram2;
SDRAM_HandleTypeDef hsdram1;

/* USER CODE BEGIN PV */
/* Private variables ---------------------------------------------------------*/

/* USER CODE END PV */

/* Private function prototypes -----------------------------------------------*/
void SystemClock_Config(void);
static void MX_GPIO_Init(void);
static void MX_DMA_Init(void);
static void MX_FMC_Init(void);
static void MX_SDMMC1_SD_Init(void);
static void MX_USART1_UART_Init(void);

/* USER CODE BEGIN PFP */
/* Private function prototypes -----------------------------------------------*/
/**
* @brief Toggles LEDs to show user input state.
* @param None
* @retval None
*/
static void Toggle_Leds(void)
{
static uint32_t ticks;

if (ticks++ == 0xFFF)
{
BSP_LED_Toggle(LED1);
BSP_LED_Toggle(LED2);
BSP_LED_Toggle(LED3);
BSP_LED_Toggle(LED4);
ticks = 0;
}
}
/* USER CODE END PFP */

/* USER CODE BEGIN 0 */

/* USER CODE END 0 */

/**
* @brief The application entry point.
*
* @retval None
*/
extern void initialise_monitor_handles(void);

int main(void)
{
initialise_monitor_handles();
/* USER CODE BEGIN 1 */
printf("Start Running \n");
/* USER CODE END 1 */

/* MCU Configuration----------------------------------------------------------*/

/* Reset of all peripherals, Initializes the Flash interface and the Systick. */
HAL_Init();

/* USER CODE BEGIN Init */

/* USER CODE END Init */

/* Configure the system clock */
SystemClock_Config();

/* USER CODE BEGIN SysInit */

/* USER CODE END SysInit */

/* Initialize all configured peripherals */
MX_GPIO_Init();
MX_DMA_Init();
MX_FMC_Init();
MX_SDMMC1_SD_Init();
MX_USART1_UART_Init();
MX_USB_DEVICE_Init();
/* USER CODE BEGIN 2 */
BSP_LED_Off(LED1);
BSP_LED_Off(LED2);
BSP_LED_Off(LED3);
BSP_LED_Off(LED4);
/* USER CODE END 2 */

/* Infinite loop */
/* USER CODE BEGIN WHILE */
printf("Test semihost \n");
while (1)
{

/* USER CODE END WHILE */
//Toggle_Leds();
/* USER CODE BEGIN 3 */

}
/* USER CODE END 3 */

}

/**
* @brief System Clock Configuration
* @retval None
*/
void SystemClock_Config(void)
{

RCC_OscInitTypeDef RCC_OscInitStruct;
RCC_ClkInitTypeDef RCC_ClkInitStruct;
RCC_PeriphCLKInitTypeDef PeriphClkInitStruct;

/**Configure the main internal regulator output voltage
*/
__HAL_RCC_PWR_CLK_ENABLE();

__HAL_PWR_VOLTAGESCALING_CONFIG(PWR_REGULATOR_VOLTAGE_SCALE3);

/**Initializes the CPU, AHB and APB busses clocks
*/
RCC_OscInitStruct.OscillatorType = RCC_OSCILLATORTYPE_HSE;
RCC_OscInitStruct.HSEState = RCC_HSE_ON;
RCC_OscInitStruct.PLL.PLLState = RCC_PLL_ON;
RCC_OscInitStruct.PLL.PLLSource = RCC_PLLSOURCE_HSE;
RCC_OscInitStruct.PLL.PLLM = 25;
RCC_OscInitStruct.PLL.PLLN = 192;
RCC_OscInitStruct.PLL.PLLP = RCC_PLLP_DIV4;
RCC_OscInitStruct.PLL.PLLQ = 4;
if (HAL_RCC_OscConfig(&RCC_OscInitStruct) != HAL_OK)
{
_Error_Handler(__FILE__, __LINE__);
}

/**Initializes the CPU, AHB and APB busses clocks
*/
RCC_ClkInitStruct.ClockType = RCC_CLOCKTYPE_HCLK|RCC_CLOCKTYPE_SYSCLK
|RCC_CLOCKTYPE_PCLK1|RCC_CLOCKTYPE_PCLK2;
RCC_ClkInitStruct.SYSCLKSource = RCC_SYSCLKSOURCE_PLLCLK;
RCC_ClkInitStruct.AHBCLKDivider = RCC_SYSCLK_DIV1;
RCC_ClkInitStruct.APB1CLKDivider = RCC_HCLK_DIV4;
RCC_ClkInitStruct.APB2CLKDivider = RCC_HCLK_DIV2;

if (HAL_RCC_ClockConfig(&RCC_ClkInitStruct, FLASH_LATENCY_1) != HAL_OK)
{
_Error_Handler(__FILE__, __LINE__);
}

PeriphClkInitStruct.PeriphClockSelection = RCC_PERIPHCLK_USART1|RCC_PERIPHCLK_SDMMC1
|RCC_PERIPHCLK_CLK48;
PeriphClkInitStruct.Usart1ClockSelection = RCC_USART1CLKSOURCE_PCLK2;
PeriphClkInitStruct.Clk48ClockSelection = RCC_CLK48SOURCE_PLL;
PeriphClkInitStruct.Sdmmc1ClockSelection = RCC_SDMMC1CLKSOURCE_CLK48;
if (HAL_RCCEx_PeriphCLKConfig(&PeriphClkInitStruct) != HAL_OK)
{
_Error_Handler(__FILE__, __LINE__);
}

/**Configure the Systick interrupt time
*/
HAL_SYSTICK_Config(HAL_RCC_GetHCLKFreq()/1000);

/**Configure the Systick
*/
HAL_SYSTICK_CLKSourceConfig(SYSTICK_CLKSOURCE_HCLK);

/* SysTick_IRQn interrupt configuration */
HAL_NVIC_SetPriority(SysTick_IRQn, 0, 0);
}

/* SDMMC1 init function */
static void MX_SDMMC1_SD_Init(void)
{

hsd1.Instance = SDMMC1;
hsd1.Init.ClockEdge = SDMMC_CLOCK_EDGE_RISING;
hsd1.Init.ClockBypass = SDMMC_CLOCK_BYPASS_DISABLE;
hsd1.Init.ClockPowerSave = SDMMC_CLOCK_POWER_SAVE_DISABLE;
hsd1.Init.BusWide = SDMMC_BUS_WIDE_1B;
hsd1.Init.HardwareFlowControl = SDMMC_HARDWARE_FLOW_CONTROL_DISABLE;
hsd1.Init.ClockDiv = 0;
if (HAL_SD_Init(&hsd1) != HAL_OK)
{
_Error_Handler(__FILE__, __LINE__);
}

if (HAL_SD_ConfigWideBusOperation(&hsd1, SDMMC_BUS_WIDE_4B) != HAL_OK)
{
_Error_Handler(__FILE__, __LINE__);
}

}

/* USART1 init function */
static void MX_USART1_UART_Init(void)
{

huart1.Instance = USART1;
huart1.Init.BaudRate = 115200;
huart1.Init.WordLength = UART_WORDLENGTH_7B;
huart1.Init.StopBits = UART_STOPBITS_1;
huart1.Init.Parity = UART_PARITY_NONE;
huart1.Init.Mode = UART_MODE_TX_RX;
huart1.Init.HwFlowCtl = UART_HWCONTROL_NONE;
huart1.Init.OverSampling = UART_OVERSAMPLING_16;
huart1.Init.OneBitSampling = UART_ONE_BIT_SAMPLE_DISABLE;
huart1.AdvancedInit.AdvFeatureInit = UART_ADVFEATURE_NO_INIT;
if (HAL_UART_Init(&huart1) != HAL_OK)
{
_Error_Handler(__FILE__, __LINE__);
}

}

/**
* Enable DMA controller clock
*/
static void MX_DMA_Init(void)
{
/* DMA controller clock enable */
__HAL_RCC_DMA2_CLK_ENABLE();

/* DMA interrupt init */
/* DMA2_Stream3_IRQn interrupt configuration */
HAL_NVIC_SetPriority(DMA2_Stream3_IRQn, 0, 0);
HAL_NVIC_EnableIRQ(DMA2_Stream3_IRQn);
/* DMA2_Stream6_IRQn interrupt configuration */
HAL_NVIC_SetPriority(DMA2_Stream6_IRQn, 0, 0);
HAL_NVIC_EnableIRQ(DMA2_Stream6_IRQn);

}
/* FMC initialization function */
static void MX_FMC_Init(void)
{
FMC_NORSRAM_TimingTypeDef Timing;
FMC_SDRAM_TimingTypeDef SdramTiming;

/** Perform the NOR1 memory initialization sequence
*/
hnor1.Instance = FMC_NORSRAM_DEVICE;
hnor1.Extended = FMC_NORSRAM_EXTENDED_DEVICE;
/* hnor1.Init */
hnor1.Init.NSBank = FMC_NORSRAM_BANK1;
hnor1.Init.DataAddressMux = FMC_DATA_ADDRESS_MUX_DISABLE;
hnor1.Init.MemoryType = FMC_MEMORY_TYPE_NOR;
hnor1.Init.MemoryDataWidth = FMC_NORSRAM_MEM_BUS_WIDTH_16;
hnor1.Init.BurstAccessMode = FMC_BURST_ACCESS_MODE_DISABLE;
hnor1.Init.WaitSignalPolarity = FMC_WAIT_SIGNAL_POLARITY_LOW;
hnor1.Init.WaitSignalActive = FMC_WAIT_TIMING_BEFORE_WS;
hnor1.Init.WriteOperation = FMC_WRITE_OPERATION_DISABLE;
hnor1.Init.WaitSignal = FMC_WAIT_SIGNAL_DISABLE;
hnor1.Init.ExtendedMode = FMC_EXTENDED_MODE_DISABLE;
hnor1.Init.AsynchronousWait = FMC_ASYNCHRONOUS_WAIT_ENABLE;
hnor1.Init.WriteBurst = FMC_WRITE_BURST_DISABLE;
hnor1.Init.ContinuousClock = FMC_CONTINUOUS_CLOCK_SYNC_ONLY;
hnor1.Init.WriteFifo = FMC_WRITE_FIFO_ENABLE;
hnor1.Init.PageSize = FMC_PAGE_SIZE_NONE;
/* Timing */
Timing.AddressSetupTime = 15;
Timing.AddressHoldTime = 15;
Timing.DataSetupTime = 255;
Timing.BusTurnAroundDuration = 15;
Timing.CLKDivision = 16;
Timing.DataLatency = 17;
Timing.AccessMode = FMC_ACCESS_MODE_A;
/* ExtTiming */

if (HAL_NOR_Init(&hnor1, &Timing, NULL) != HAL_OK)
{
_Error_Handler(__FILE__, __LINE__);
}

/** Perform the SRAM2 memory initialization sequence
*/
hsram2.Instance = FMC_NORSRAM_DEVICE;
hsram2.Extended = FMC_NORSRAM_EXTENDED_DEVICE;
/* hsram2.Init */
hsram2.Init.NSBank = FMC_NORSRAM_BANK3;
hsram2.Init.DataAddressMux = FMC_DATA_ADDRESS_MUX_DISABLE;
hsram2.Init.MemoryType = FMC_MEMORY_TYPE_SRAM;
hsram2.Init.MemoryDataWidth = FMC_NORSRAM_MEM_BUS_WIDTH_16;
hsram2.Init.BurstAccessMode = FMC_BURST_ACCESS_MODE_DISABLE;
hsram2.Init.WaitSignalPolarity = FMC_WAIT_SIGNAL_POLARITY_LOW;
hsram2.Init.WaitSignalActive = FMC_WAIT_TIMING_BEFORE_WS;
hsram2.Init.WriteOperation = FMC_WRITE_OPERATION_DISABLE;
hsram2.Init.WaitSignal = FMC_WAIT_SIGNAL_DISABLE;
hsram2.Init.ExtendedMode = FMC_EXTENDED_MODE_DISABLE;
hsram2.Init.AsynchronousWait = FMC_ASYNCHRONOUS_WAIT_ENABLE;
hsram2.Init.WriteBurst = FMC_WRITE_BURST_DISABLE;
hsram2.Init.ContinuousClock = FMC_CONTINUOUS_CLOCK_SYNC_ONLY;
hsram2.Init.WriteFifo = FMC_WRITE_FIFO_ENABLE;
hsram2.Init.PageSize = FMC_PAGE_SIZE_NONE;
/* Timing */
Timing.AddressSetupTime = 15;
Timing.AddressHoldTime = 15;
Timing.DataSetupTime = 255;
Timing.BusTurnAroundDuration = 15;
Timing.CLKDivision = 16;
Timing.DataLatency = 17;
Timing.AccessMode = FMC_ACCESS_MODE_A;
/* ExtTiming */

if (HAL_SRAM_Init(&hsram2, &Timing, NULL) != HAL_OK)
{
_Error_Handler(__FILE__, __LINE__);
}

/** Perform the SDRAM1 memory initialization sequence
*/
hsdram1.Instance = FMC_SDRAM_DEVICE;
/* hsdram1.Init */
hsdram1.Init.SDBank = FMC_SDRAM_BANK1;
hsdram1.Init.ColumnBitsNumber = FMC_SDRAM_COLUMN_BITS_NUM_8;
hsdram1.Init.RowBitsNumber = FMC_SDRAM_ROW_BITS_NUM_13;
hsdram1.Init.MemoryDataWidth = FMC_SDRAM_MEM_BUS_WIDTH_32;
hsdram1.Init.InternalBankNumber = FMC_SDRAM_INTERN_BANKS_NUM_4;
hsdram1.Init.CASLatency = FMC_SDRAM_CAS_LATENCY_1;
hsdram1.Init.WriteProtection = FMC_SDRAM_WRITE_PROTECTION_DISABLE;
hsdram1.Init.SDClockPeriod = FMC_SDRAM_CLOCK_DISABLE;
hsdram1.Init.ReadBurst = FMC_SDRAM_RBURST_DISABLE;
hsdram1.Init.ReadPipeDelay = FMC_SDRAM_RPIPE_DELAY_0;
/* SdramTiming */
SdramTiming.LoadToActiveDelay = 16;
SdramTiming.ExitSelfRefreshDelay = 16;
SdramTiming.SelfRefreshTime = 16;
SdramTiming.RowCycleDelay = 16;
SdramTiming.WriteRecoveryTime = 16;
SdramTiming.RPDelay = 16;
SdramTiming.RCDDelay = 16;

if (HAL_SDRAM_Init(&hsdram1, &SdramTiming) != HAL_OK)
{
_Error_Handler(__FILE__, __LINE__);
}

}

/** Configure pins
PE2 ------> ETH_TXD3
PG14 ------> ETH_TXD1
PB8 ------> I2C1_SCL
PB4 ------> SDMMC2_D3
PB3 ------> SDMMC2_D2
PD7 ------> SDMMC2_CMD
PE6 ------> SAI2_MCLK_B
PG13 ------> ETH_TXD0
PB9 ------> I2C1_SDA
PB7 ------> DCMI_VSYNC
PB6 ------> QUADSPI_BK1_NCS
PG11 ------> ETH_TX_EN
PD6 ------> SDMMC2_CK
PA12 ------> USB_OTG_FS_DP
PK7 ------> LTDC_DE
PK6 ------> LTDC_B7
PK5 ------> LTDC_B6
PG12 ------> SPDIFRX_IN1
PG10 ------> SDMMC2_D1
PJ14 ------> LTDC_B2
PD3 ------> DCMI_D5
PA11 ------> USB_OTG_FS_DM
PK4 ------> LTDC_B5
PK3 ------> LTDC_B4
PG9 ------> SAI2_FS_B
PJ15 ------> LTDC_B3
PI12 ------> LTDC_HSYNC
PA8 ------> RCC_MCO_1
PI13 ------> LTDC_VSYNC
PI14 ------> LTDC_CLK
PF7 ------> QUADSPI_BK1_IO2
PF6 ------> QUADSPI_BK1_IO3
PF10 ------> ADC3_IN8
PF9 ------> QUADSPI_BK1_IO1
PF8 ------> QUADSPI_BK1_IO0
PC3 ------> ETH_TX_CLK
PC1 ------> SAI1_SD_A
PC2 ------> ETH_TXD2
PB2 ------> QUADSPI_CLK
PJ4 ------> LTDC_R5
PJ5 ------> LTDC_R6
PA1 ------> ETH_RX_CLK
PA0/WKUP ------> SAI2_SD_B
PA4 ------> DCMI_HSYNC
PC4 ------> ETH_RXD0
PH7 ------> ETH_RXD3
PA2 ------> SAI2_SCK_B
PA6 ------> DCMI_PIXCLK
PC5 ------> ETH_RXD1
PJ2 ------> DSIHOST_TE
PH6 ------> ETH_RXD2
PA7 ------> ETH_RX_DV
*/
static void MX_GPIO_Init(void)
{

GPIO_InitTypeDef GPIO_InitStruct;

/* GPIO Ports Clock Enable */
__HAL_RCC_GPIOE_CLK_ENABLE();
__HAL_RCC_GPIOG_CLK_ENABLE();
__HAL_RCC_GPIOB_CLK_ENABLE();
__HAL_RCC_GPIOD_CLK_ENABLE();
__HAL_RCC_GPIOC_CLK_ENABLE();
__HAL_RCC_GPIOA_CLK_ENABLE();
__HAL_RCC_GPIOJ_CLK_ENABLE();
__HAL_RCC_GPIOI_CLK_ENABLE();
__HAL_RCC_GPIOK_CLK_ENABLE();
__HAL_RCC_GPIOF_CLK_ENABLE();
__HAL_RCC_GPIOH_CLK_ENABLE();

/*Configure GPIO pin Output Level */
HAL_GPIO_WritePin(GPIOJ, MII_MDC_GPIO_Pin|MII_MDIO_GPIO_Pin|LED3_Pin|LED1_Pin
|LED2_Pin, GPIO_PIN_RESET);

/*Configure GPIO pin Output Level */
HAL_GPIO_WritePin(LED0_GPIO_Port, LED0_Pin, GPIO_PIN_RESET);

/*Configure GPIO pin : MII_TXD3_Pin */
GPIO_InitStruct.Pin = MII_TXD3_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF11_ETH;
HAL_GPIO_Init(MII_TXD3_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pins : MII_TXD1_Pin MII_TXD0_Pin MII_TX_EN_Pin */
GPIO_InitStruct.Pin = MII_TXD1_Pin|MII_TXD0_Pin|MII_TX_EN_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF11_ETH;
HAL_GPIO_Init(GPIOG, &GPIO_InitStruct);

/*Configure GPIO pins : I2C1_SCL_Pin I2C1_SDA_Pin */
GPIO_InitStruct.Pin = I2C1_SCL_Pin|I2C1_SDA_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_OD;
GPIO_InitStruct.Pull = GPIO_PULLUP;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF4_I2C1;
HAL_GPIO_Init(GPIOB, &GPIO_InitStruct);

/*Configure GPIO pins : SD2_D3_Pin SD2_D2_Pin */
GPIO_InitStruct.Pin = SD2_D3_Pin|SD2_D2_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF10_SDMMC2;
HAL_GPIO_Init(GPIOB, &GPIO_InitStruct);

/*Configure GPIO pins : SD2_CMD_Pin SD2_CLK_Pin */
GPIO_InitStruct.Pin = SD2_CMD_Pin|SD2_CLK_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF11_SDMMC2;
HAL_GPIO_Init(GPIOD, &GPIO_InitStruct);

/*Configure GPIO pin : SAI2_MCLKB_Pin */
GPIO_InitStruct.Pin = SAI2_MCLKB_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF10_SAI2;
HAL_GPIO_Init(SAI2_MCLKB_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pin : PAR_VSYNC_Pin */
GPIO_InitStruct.Pin = PAR_VSYNC_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF13_DCMI;
HAL_GPIO_Init(PAR_VSYNC_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pin : QSPI_BK1_NCS_Pin */
GPIO_InitStruct.Pin = QSPI_BK1_NCS_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF10_QUADSPI;
HAL_GPIO_Init(QSPI_BK1_NCS_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pins : MII_MDC_GPIO_Pin MII_MDIO_GPIO_Pin LED3_Pin LED1_Pin
LED2_Pin */
GPIO_InitStruct.Pin = MII_MDC_GPIO_Pin|MII_MDIO_GPIO_Pin|LED3_Pin|LED1_Pin
|LED2_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_OUTPUT_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
HAL_GPIO_Init(GPIOJ, &GPIO_InitStruct);

/*Configure GPIO pins : USB_FS1_DP_Pin USB_FS1_DM_Pin */
GPIO_InitStruct.Pin = USB_FS1_DP_Pin|USB_FS1_DM_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF10_OTG_FS;
HAL_GPIO_Init(GPIOA, &GPIO_InitStruct);

/*Configure GPIO pin : EXPANDER_INT_Pin */
GPIO_InitStruct.Pin = EXPANDER_INT_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_IT_RISING;
GPIO_InitStruct.Pull = GPIO_NOPULL;
HAL_GPIO_Init(EXPANDER_INT_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pins : LCD_DE_Pin LCD_B7_Pin LCD_B6_Pin LCD_B5_Pin
LCD_B4_Pin */
GPIO_InitStruct.Pin = LCD_DE_Pin|LCD_B7_Pin|LCD_B6_Pin|LCD_B5_Pin
|LCD_B4_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF14_LTDC;
HAL_GPIO_Init(GPIOK, &GPIO_InitStruct);

/*Configure GPIO pin : SPDIF_RX1_Pin */
GPIO_InitStruct.Pin = SPDIF_RX1_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF7_SPDIFRX;
HAL_GPIO_Init(SPDIF_RX1_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pin : SD2_D1_Pin */
GPIO_InitStruct.Pin = SD2_D1_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF11_SDMMC2;
HAL_GPIO_Init(SD2_D1_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pins : LCD_B2_Pin LCD_B3_Pin LCD_R5_Pin LCD_R6_Pin */
GPIO_InitStruct.Pin = LCD_B2_Pin|LCD_B3_Pin|LCD_R5_Pin|LCD_R6_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF14_LTDC;
HAL_GPIO_Init(GPIOJ, &GPIO_InitStruct);

/*Configure GPIO pin : PAR_D5_Pin */
GPIO_InitStruct.Pin = PAR_D5_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF13_DCMI;
HAL_GPIO_Init(PAR_D5_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pin : TAMPER_WKUP_KEY_Pin */
GPIO_InitStruct.Pin = TAMPER_WKUP_KEY_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_IT_RISING;
GPIO_InitStruct.Pull = GPIO_NOPULL;
HAL_GPIO_Init(TAMPER_WKUP_KEY_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pin : SAI2_FSB_Pin */
GPIO_InitStruct.Pin = SAI2_FSB_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF10_SAI2;
HAL_GPIO_Init(SAI2_FSB_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pins : LCD_HSYNC_Pin LCD_VSYNC_Pin LCD_CLK_Pin */
GPIO_InitStruct.Pin = LCD_HSYNC_Pin|LCD_VSYNC_Pin|LCD_CLK_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF14_LTDC;
HAL_GPIO_Init(GPIOI, &GPIO_InitStruct);

/*Configure GPIO pin : MII_MCO_Pin */
GPIO_InitStruct.Pin = MII_MCO_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF0_MCO;
HAL_GPIO_Init(MII_MCO_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pin : LED0_Pin */
GPIO_InitStruct.Pin = LED0_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_OUTPUT_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
HAL_GPIO_Init(LED0_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pins : QSPI_BK1_IO2_Pin QSPI_BK1_IO3_Pin */
GPIO_InitStruct.Pin = QSPI_BK1_IO2_Pin|QSPI_BK1_IO3_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF9_QUADSPI;
HAL_GPIO_Init(GPIOF, &GPIO_InitStruct);

/*Configure GPIO pin : Potentiometer_Pin */
GPIO_InitStruct.Pin = Potentiometer_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_ANALOG;
GPIO_InitStruct.Pull = GPIO_NOPULL;
HAL_GPIO_Init(Potentiometer_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pins : QSPI_BK1_IO1_Pin QSPI_BK1_IO0_Pin */
GPIO_InitStruct.Pin = QSPI_BK1_IO1_Pin|QSPI_BK1_IO0_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF10_QUADSPI;
HAL_GPIO_Init(GPIOF, &GPIO_InitStruct);

/*Configure GPIO pins : MII_TX_CLK_Pin MII_TXD2_Pin MII_RXD0_Pin MII_RXD1_Pin */
GPIO_InitStruct.Pin = MII_TX_CLK_Pin|MII_TXD2_Pin|MII_RXD0_Pin|MII_RXD1_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF11_ETH;
HAL_GPIO_Init(GPIOC, &GPIO_InitStruct);

/*Configure GPIO pin : SAI1_SDA_Pin */
GPIO_InitStruct.Pin = SAI1_SDA_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF6_SAI1;
HAL_GPIO_Init(SAI1_SDA_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pin : QSPI_CLK_Pin */
GPIO_InitStruct.Pin = QSPI_CLK_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF9_QUADSPI;
HAL_GPIO_Init(QSPI_CLK_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pins : MII_RX_CLK_Pin MII_RX_DV_Pin */
GPIO_InitStruct.Pin = MII_RX_CLK_Pin|MII_RX_DV_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF11_ETH;
HAL_GPIO_Init(GPIOA, &GPIO_InitStruct);

/*Configure GPIO pin : SAI2_SDB_Pin */
GPIO_InitStruct.Pin = SAI2_SDB_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF10_SAI2;
HAL_GPIO_Init(SAI2_SDB_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pins : PAR_HSYNC_Pin PAR_PCLK_Pin */
GPIO_InitStruct.Pin = PAR_HSYNC_Pin|PAR_PCLK_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF13_DCMI;
HAL_GPIO_Init(GPIOA, &GPIO_InitStruct);

/*Configure GPIO pins : MII_RXD3_Pin MII_RXD2_Pin */
GPIO_InitStruct.Pin = MII_RXD3_Pin|MII_RXD2_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_VERY_HIGH;
GPIO_InitStruct.Alternate = GPIO_AF11_ETH;
HAL_GPIO_Init(GPIOH, &GPIO_InitStruct);

/*Configure GPIO pin : SAI2_SCKB_Pin */
GPIO_InitStruct.Pin = SAI2_SCKB_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF8_SAI2;
HAL_GPIO_Init(SAI2_SCKB_GPIO_Port, &GPIO_InitStruct);

/*Configure GPIO pin : DSI_TE_Pin */
GPIO_InitStruct.Pin = DSI_TE_Pin;
GPIO_InitStruct.Mode = GPIO_MODE_AF_PP;
GPIO_InitStruct.Pull = GPIO_NOPULL;
GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_LOW;
GPIO_InitStruct.Alternate = GPIO_AF13_DSI;
HAL_GPIO_Init(DSI_TE_GPIO_Port, &GPIO_InitStruct);

}

/* USER CODE BEGIN 4 */

/* USER CODE END 4 */

/**
* @brief This function is executed in case of error occurrence.
* @param file: The file name as string.
* @param line: The line in file as a number.
* @retval None
*/
void _Error_Handler(char *file, int line)
{
/* USER CODE BEGIN Error_Handler_Debug */
/* User can add his own implementation to report the HAL error return state */
while(1)
{
}
/* USER CODE END Error_Handler_Debug */
}

#ifdef USE_FULL_ASSERT
/**
* @brief Reports the name of the source file and the source line number
* where the assert_param error has occurred.
* @param file: pointer to the source file name
* @param line: assert_param error line source number
* @retval None
*/
void assert_failed(uint8_t* file, uint32_t line)
{
/* USER CODE BEGIN 6 */
/* User can add his own implementation to report the file name and line number,
tex: printf("Wrong parameters value: file %s on line %d\r\n", file, line) */
/* USER CODE END 6 */
}
#endif /* USE_FULL_ASSERT */

/**
* @}
*/

/**
* @}
*/

/************************ (C) COPYRIGHT STMicroelectronics *****END OF FILE****/



And this is usbd_storage_if.c

/* Includes ------------------------------------------------------------------*/
#include "usbd_storage_if.h"

/* USER CODE BEGIN INCLUDE */

/* USER CODE END INCLUDE */

/* Private typedef -----------------------------------------------------------*/
/* Private define ------------------------------------------------------------*/
#define SD_WAIT_TIMEOUT 1000
/* Private macro -------------------------------------------------------------*/

/* USER CODE BEGIN PV */
/* Private variables ---------------------------------------------------------*/
__IO uint32_t writestatus, readstatus = 0;
/* USER CODE END PV */

/** @addtogroup STM32_USB_OTG_DEVICE_LIBRARY
* @brief Usb device.
* @{
*/

/** @defgroup USBD_STORAGE
* @brief Usb mass storage device module
* @{
*/

/** @defgroup USBD_STORAGE_Private_TypesDefinitions
* @brief Private types.
* @{
*/

/* USER CODE BEGIN PRIVATE_TYPES */

/* USER CODE END PRIVATE_TYPES */

/**
* @}
*/

/** @defgroup USBD_STORAGE_Private_Defines
* @brief Private defines.
* @{
*/

#define STORAGE_LUN_NBR 1
#define STORAGE_BLK_NBR 0x10000
#define STORAGE_BLK_SIZ 0x200

/* USER CODE BEGIN PRIVATE_DEFINES */

/* USER CODE END PRIVATE_DEFINES */

/**
* @}
*/

/** @defgroup USBD_STORAGE_Private_Macros
* @brief Private macros.
* @{
*/

/* USER CODE BEGIN PRIVATE_MACRO */

/* USER CODE END PRIVATE_MACRO */

/**
* @}
*/

/** @defgroup USBD_STORAGE_Private_Variables
* @brief Private variables.
* @{
*/

/* USER CODE BEGIN INQUIRY_DATA_HS */
/** USB Mass storage Standard Inquiry Data. */
const int8_t STORAGE_Inquirydata_HS[] = {/* 36 */

/* LUN 0 */
0x00,
0x80,
0x02,
0x02,
(STANDARD_INQUIRY_DATA_LEN - 5),
0x00,
0x00,
0x00,
'S', 'T', 'M', ' ', ' ', ' ', ' ', ' ', /* Manufacturer : 8 bytes */
'P', 'r', 'o', 'd', 'u', 'c', 't', ' ', /* Product : 16 Bytes */
' ', ' ', ' ', ' ', ' ', ' ', ' ', ' ',
'0', '.', '0' ,'1' /* Version : 4 Bytes */
};
/* USER CODE END INQUIRY_DATA_HS */

/* USER CODE BEGIN PRIVATE_VARIABLES */

/* USER CODE END PRIVATE_VARIABLES */

/**
* @}
*/

/** @defgroup USBD_STORAGE_Exported_Variables
* @brief Public variables.
* @{
*/
extern SD_HandleTypeDef hsd1;
HAL_SD_CardInfoTypeDef SDCardInfo;
/* USER CODE BEGIN EXPORTED_VARIABLES */

/* USER CODE END EXPORTED_VARIABLES */

/**
* @}
*/

/** @defgroup USBD_STORAGE_Private_FunctionPrototypes
* @brief Private functions declaration.
* @{
*/

static int8_t STORAGE_Init_HS(uint8_t lun);
static int8_t STORAGE_GetCapacity_HS(uint8_t lun, uint32_t *block_num, uint16_t *block_size);
static int8_t STORAGE_IsReady_HS(uint8_t lun);
static int8_t STORAGE_IsWriteProtected_HS(uint8_t lun);
static int8_t STORAGE_Read_HS(uint8_t lun, uint8_t *buf, uint32_t blk_addr, uint16_t blk_len);
static int8_t STORAGE_Write_HS(uint8_t lun, uint8_t *buf, uint32_t blk_addr, uint16_t blk_len);
static int8_t STORAGE_GetMaxLun_HS(void);

/* USER CODE BEGIN PRIVATE_FUNCTIONS_DECLARATION */

/* USER CODE END PRIVATE_FUNCTIONS_DECLARATION */

/**
* @}
*/

USBD_StorageTypeDef USBD_Storage_Interface_fops_HS =
{
STORAGE_Init_HS,
STORAGE_GetCapacity_HS,
STORAGE_IsReady_HS,
STORAGE_IsWriteProtected_HS,
STORAGE_Read_HS,
STORAGE_Write_HS,
STORAGE_GetMaxLun_HS,
(int8_t *)STORAGE_Inquirydata_HS
};

/* Private functions ---------------------------------------------------------*/

/**
* @brief .
* @param lun: .
* @retval USBD_OK if all operations are OK else USBD_FAIL
*/
int8_t STORAGE_Init_HS(uint8_t lun)
{
/* USER CODE BEGIN 9 */
printf("STORAGE_Init_HS \n");
return (USBD_OK);
/* USER CODE END 9 */
}

/**
* @brief .
* @param lun: .
* @param block_num: .
* @param block_size: .
* @retval USBD_OK if all operations are OK else USBD_FAIL
*/
int8_t STORAGE_GetCapacity_HS(uint8_t lun, uint32_t *block_num, uint16_t *block_size)
{
/* USER CODE BEGIN 10 */
printf("begin STORAGE_GetCapacity_HS \n");

HAL_SD_GetCardInfo(&hsd1, &SDCardInfo);
printf("SDCardInfo.BlockNbr %d \n", SDCardInfo.BlockNbr);
printf("SDCardInfo.BlockSize %d \n", SDCardInfo.BlockSize);
*block_num = SDCardInfo.BlockNbr - 1;
*block_size = SDCardInfo.BlockSize;
printf("end STORAGE_GetCapacity_HS \n");
return (USBD_OK);
/* USER CODE END 10 */
}

/**
* @brief .
* @param lun: .
* @retval USBD_OK if all operations are OK else USBD_FAIL
*/
int8_t STORAGE_IsReady_HS(uint8_t lun)
{
/* USER CODE BEGIN 11 */
printf("STORAGE_IsReady_HS \n");
return (USBD_OK);
/* USER CODE END 11 */
}

/**
* @brief .
* @param lun: .
* @retval USBD_OK if all operations are OK else USBD_FAIL
*/
int8_t STORAGE_IsWriteProtected_HS(uint8_t lun)
{
/* USER CODE BEGIN 12 */
printf("STORAGE_IsWriteProtected_HS \n");
return (USBD_OK);
/* USER CODE END 12 */
}

/**
* @brief .
* @param lun: .
* @param buf: .
* @param blk_addr: .
* @param blk_len: .
* @retval USBD_OK if all operations are OK else USBD_FAIL
*/
int8_t STORAGE_Read_HS(uint8_t lun, uint8_t *buf, uint32_t blk_addr, uint16_t blk_len)
{
/* USER CODE BEGIN 13 */
printf("begin STORAGE_Read_HS \n");
HAL_SD_CardStateTypeDef sd_card_state_return;
uint32_t timeout = 0;
if(HAL_OK != HAL_SD_ReadBlocks_DMA(&hsd1, buf, blk_addr, blk_len))
{
printf("Error : STORAGE_Read_HS failed\n");
return USBD_FAIL;
}

/* Wait for Rx Transfer completion */
// while (readstatus == 0)
// {
// }
// readstatus = 0;

/*wait until the card finish read/write*/
do
{
sd_card_state_return = HAL_SD_GetCardState(&hsd1);
timeout++;
} while((HAL_SD_CARD_TRANSFER != sd_card_state_return) && (SD_WAIT_TIMEOUT > timeout));

if((SD_WAIT_TIMEOUT <= timeout))
{
printf("Error : STORAGE_Read_HS HAL_TIMEOUT\n");
return HAL_TIMEOUT;
}
printf("end STORAGE_Read_HS \n");
return (USBD_OK);
/* USER CODE END 13 */
}

/**
* @brief .
* @param lun: .
* @param buf: .
* @param blk_addr: .
* @param blk_len: .
* @retval USBD_OK if all operations are OK else USBD_FAIL
*/
int8_t STORAGE_Write_HS(uint8_t lun, uint8_t *buf, uint32_t blk_addr, uint16_t blk_len)
{
/* USER CODE BEGIN 14 */
printf("STORAGE_Write_HS \n");
HAL_SD_CardStateTypeDef sd_card_state_return;
uint32_t timeout = 0;
if(HAL_OK != HAL_SD_WriteBlocks_DMA(&hsd1, buf, blk_addr, (uint32_t) blk_len))
{
return USBD_FAIL;
}

/* Wait for Tx Transfer completion */
// while (writestatus == 0)
// {
// }
// writestatus = 0;

/*wait until the card finish read/write*/
do
{
sd_card_state_return = HAL_SD_GetCardState(&hsd1);
timeout++;
} while((HAL_SD_CARD_TRANSFER != sd_card_state_return) && (SD_WAIT_TIMEOUT > timeout));

if((SD_WAIT_TIMEOUT <= timeout))
{
return HAL_TIMEOUT;
}
return (USBD_OK);
/* USER CODE END 14 */
}

/**
* @brief .
* @param None
* @retval .
*/
int8_t STORAGE_GetMaxLun_HS(void)
{
/* USER CODE BEGIN 15 */
printf("STORAGE_GetMaxLun_HS \n");
return (STORAGE_LUN_NBR - 1);
/* USER CODE END 15 */
}

/* USER CODE BEGIN PRIVATE_FUNCTIONS_IMPLEMENTATION */

/**
* @brief BSP Tx Transfer completed callbacks
* @param None
* @retval None
*/
void HAL_SD_TxCpltCallback(SD_HandleTypeDef *hsd)
{
writestatus = 1;
}

/**
* @brief BSP Rx Transfer completed callbacks
* @param None
* @retval None
*/
void HAL_SD_RxCpltCallback(SD_HandleTypeDef *hsd)
{
readstatus = 1;
}
/* USER CODE END PRIVATE_FUNCTIONS_IMPLEMENTATION */

/**
* @}
*/

/**
* @}
*/

/************************ (C) COPYRIGHT STMicroelectronics *****END OF FILE****/



Could you help me review what the issue is . i tried to debug the  in usbd_storage_if.c.

When I plug in the USB cable , the program keep calling the  STORAGE_GetCapacity_HS and STORAGE_Read_HS

is it correct ?



The Attachment if the full source code .

Attachments

Outcomes
